Andersen 100 Series Gliding Patio Door


100 Series Gliding Patio Door

Active Star Active Star Active Star Active Star Active Star

View Reviews

Andersen 100 Series patio doors fit nicely in tight spaces. The operable panel on this door glides horizontally and won't interfere with your room or patio.

  • Made in USA
  • Energy Star certified to help you save energy
  • 44 years of Remodeling Excellence

Andersen 100 Series Gliding Patio Doors are the perfect choice for homeowners interested in a dependable gliding door with a contemporary feel. Andersen offers several color and hardware options allowing you to create a door that works well with your interior design.

This patio door is made with Andersen's own Fibrex® composite material, a sustainably manufactured, durable, and energy-efficient material. This gliding patio door has one panel that glides horizontally and one fixed panel. Gliding doors are a good choice in tight spaces because they don't swing out to take more space from your room or patio. Additionally, the 2-panel configuration allows more light to enter and brighten your space.

  • Fibrex material blocks thermal transfer nearly 700 times better than aluminum
  • Durable low-maintenance finish won't fade, flake, blister or peel
  • Dual-felt weatherstripping creates a positive seal between the frame and panel to protect against wind, water, and dust
  • Designed to meet or exceed performance requirements in all 50 states
  • Can withstand temperatures in excess of 160 degrees F, even in dark colors

Protected by Andersen's Owner-2-Owner Limited Warranty

  • Features
  • Colors
  • Hardware
  • Grilles
  • Glass
  • Screens
  • More Options

Gliding Patio Door Features

  • Low-Maintenance

    • Constructed with Fibrex® composite material which produces a rigid frame
    • Durable low-maintenance finish won't fade, flake, blister or peel
    • One-piece sill design with weep holes provides superior water management
    • Dual-felt weatherstripping is applied on the inside pocket of both side jambs and the head jamb resulting in an energy-efficient barrier against wind, water, and dust
  • Smooth Operation

    • Dual corrosion-resistant ball-bearing rollers on the operating door panel provide smooth operation with self-contained leveling adjusters
    • Rollers have deep grooves for increased engagement with the track which aids in resistance against lateral movement
    • A metal reinforcement is inserted into the panel to provide additional stability
  • Enhanced Security

    • Two-point locking system engages a steel receiver plate that is secured into the side jamb
    • Provides enhanced security and a weather tight seal with the operating panel pulled tightly into the jamb

Interior Color

  • Black
  • Dark Bronze
  • Sandtone
  • White

Exterior Color

  • Black
  • Dark Bronze
  • Sandtone
  • White
  • Units with Black, Dark Bronze and Sandtone interiors have matching exteriors.


Hardware Colors

  • White
  • Sandtone
  • Black
  • Satin Nickel
  • Antique Brass
  • Bright Brass

Hardware Styles

  • Afton

    Afton hardware has the same finish inside and out.

  • Tulsa

    Tulsa hardware coordinates with interior and exterior door colors.

  • Auxiliary Foot Lock

    Provides an extra measure of security when the door is in a locked position. Lock can be set so the door is fully closed or partially open to provide a secure venting position.


Grille Types

  • Finelight Grilles Between-the-Glass

    Grilles sit between the panes of glass for easy cleaning.

  • Finelight Between-the-Glass With Exterior Grilles

    Permanent grilles on the exterior provide architectural style and detail to the window while grilles between-the-glass allow easy interior side cleaning.

  • Full Divided Light

    Grilles applied to the interior and exterior of the window with aluminum spacers between the glass create an authentic look.

  • Simulated Divided Light

    Style your window with permanent exterior grilles and choose between permanent or removable interior grilles.

Grille Patterns

  • Display Image
  • Display Image
  • Display Image
    Short Fractional
  • Display Image
    Specified Equal Light

Glass Options

  • Low-E SmartSun™ Tempered Glass

    SmartSun™ glass gives you the benefits of Low-E glass, plus it helps shield your home from the sun's heat by filtering out harmful UV rays.

    Ideal for: All Climates

    Low-E SmartSun™ with HeatLock Coating is also available on 100 Series windows and doors. This prevents more heat from escaping your home but slightly reduces the visible light transmitted through the glass.

  • Low-E Tempered Glass

    Low-E Glass reflects heat in the summer and helps to retain interior heat in the winter.

    Ideal for: All Climates

    Low-E with HeatLock Coating is also available on 100 Series windows and doors. This improves the U-Factor performance of the window but slightly reduces how much light comes through the glass.

  • Sun Tempered Glass

    Sun glass has excellent thermal performance. This glass has a subtle tint that blocks out more heat from the sun.

    Ideal for: Southern Climates

  • Dual-Pane Tempered Glass

    Clear dual-pane glass, which offers basic thermal performance, is in situations where codes allow its use. In North Texas, clear-dual pane glass does not meet energy code.

    See local code official for requirements in your area.

  • HeatLock® Technology

    HeatLock® coating reflects heat that likes to escape your home through window glass. It can be added to most of Andersen's glass options.

Decorative and Specialty Glass

  • Safety Glass
    Tempered safety glass is available on all products, and comes standard on all patio doors.

    Sound-Reducing Glass
    This glass helps reduce the volume of outside noise.  Available with Low-E, SmartSun and HeatLock coatings.

    Patterned Glass
    Let in light while obscuring vision and adding a unique decorative touch to your home.

    Andersen patterned glass is available in cascade, fern, obscure, or reed patterns.


Insect Screens

  • Insect screens are available with a gray fiberglass screen mesh and are color-matched to the door exterior. The latch mechanism is contained within the insect screen handle for easy operation. Gliding insect screens are available for two-panel doors.

More Options

Sidelights & Transoms

  • Patio door sidelights and transoms are available for 100 Series gliding patio doors.

Smart Home

  • Wireless Open/Closed Sensors

    When you want the peace of mind of knowing whether your windows and patio doors are open or closed, these sensors are a simple, reliable solution.

    • Preserves Beauty.
      Sleek, compact design for a clean appearance and a variety of color options to help sensors blend in with your windows, patio doors, and home décor
    • Installation.
      Easy DIY installation
    • Maintains Warranty.
      Other sensors require drilling which can void warranties. Smart Home Wireless open/closed sensors require no drilling and come with their own limited warranty
    • Monitoring Options.
      Available with professional and/or self-monitoring options
    • Compatibility.
      Available for use with all Andersen® windows and patio doors

    Wireless Open/Closed Sensor Colors

    Andersen Wireless Open/Closed Sensor Colors: Dark Bronze, Sandtone, Canvas, Andersen White

Simply put, the 100 Series Gliding Patio Door was a night and day difference in all areas. The looks and functionality are second to none. Opens and closes as if it were riding on air. Quality manufacturing. Thank you Anderson!

— Delorean, Review from

Product Specs

Brand Andersen
Series 100-Series
Interior Color Black, Dark Bronze, Sandtone, White
Exterior Color Black, Dark Bronze, Terratone, Sandtone, White
Composition Fibrex
Construction Type Build, Remodel, Replace
Standard Heights 6'8", 6'11" and 8'
Standard Widths 5', 6', and 8'
Custom Sizes Available in 1/8" increments
Flange Setback 1-3/8"
Flange Setback w/Stucco Key 1"
Frame Depth 3-1/4"
Energy Star Certification Yes
NFRC Ratings Yes
WDMA Hallmark Certification Yes
AAMA Certification Yes
Glass Warranty 20-Years
Glass Breakage Warranty No
Non-Glass Warranty 10-Years
Labor Warranty No
