Andersen 200 Series Perma-Shield Gliding Patio Doors
Andersen's PermaShield Patio Door is one of Andersen's longest running designs. The Perma-Shield exterior and interior will never need painting and won't peel, blister, flake, or corrode.
The gliding door's exterior frame is protected by a tough vinyl that resists dents, repels water, and provides long-lasting protection making this a great choice for homeowners and builders interested in a low-maintenance, high-value patio door.
- Weather-resistant construction for greater comfort and energy efficiency
- Weatherstripping is designed to seal out drafts, wind, and water
- Slim profiles maximize your view
- Available in single panel and 2-panel configurations with custom sizes available
- Convenient Blinds-Between-the-Glass are now available for select gliding patio door sizes
Protected by Andersen's Owner-2-Owner Limited Warranty
200 Series Brochure
It Worked
Your Andersen 200 Series Perma-Shield Gliding Patio Doors Brochure is in your inbox.
- Features
- Colors
- Hardware
- Grilles
- Glass
- Screens & Blinds
- More Options
Features
Perma-Shield Gliding Patio Door Features
-
Low Maintenance
The Sill
- The sill has an extruded aluminum track, with a stainless steel cap that resists stain, rust and denting and an attractive wear-resistant, heat-baked finish in a neutral gray color.
The Frame
- The exterior frame is covered with rigid vinyl that maintains an attractive appearance while minimizing maintenance.
- The wood frame is treated with a water-repellent preservative for long-lasting protection and performance.
- A flexible vinyl weatherstrip provides a positive seal between the frame and panels.
-
Enhanced Security
The unique Andersen reach out locking hardware pulls the door panel snugly into the jamb for a weathertight seal and enhanced security.
Size and Panel Options
-
Single Panel (stationary)
- Width Options: 38-3/8", 50-3/8"
- Height Options: 82-3/8", 95-1/2"
-
Two Panel
- Width Options: 59-1/4", 70-1/2", 72", 96"
- Height Options: 79-1/2", 82-3/8", 95-1/2"
Colors
Interior
-
White
-
Sandtone
-
Terratone
-
Canvas
-
Dark Bronze
-
Black
Exterior
-
White
-
Sandtone
-
Terratone
-
Canvas
-
Dark Bronze
-
Black
Hardware
Hardware Colors
-
Antique Brass
-
Black
-
Bright Brass
-
Brushed Chrome
-
Distressed Bronze
-
Distressed Nickel
-
Gold Dust
-
Oil Rubbed Bronze
-
Polished Chrome
-
Satin Nickel
-
Stone
-
White
Hardware Styles
-
Yuma®
-
Encino®
-
Anvers®
-
Newbury®
-
Covington™
-
Whitmore®
-
Albany
-
Tribeca®
-
Hardware colors limited to certain styles.
Additional Options
-
Exterior Keyed Lock
A six-pin key cylinder lock is available in styles and finishes that coordinate with hardware and allows the door to be locked and unlocked from the exterior.
-
Auxiliary Foot Lock
Provides an extra measure of security when the door is in a locked position. Lock can be set so the door is fully closed or partially open to provide a secure venting position.
Grilles
Grille Styles
-
Simulated Divided Light
Style your window with permanent exterior grilles and choose between permanent or removable interior grilles.
-
Removable Interior Grille
Removable interior wood grilles are secured via a fastener or grille clip and can be removed enabling you to easily clean the glass surface.
-
Finelight Grilles Between-the-Glass
Grilles sit between the panes of glass for easy cleaning.
Grille Patterns
-
Colonial
-
Modified Colonial
-
Modified Colonial - Simulated Check Rail
-
Prairie
-
Short Fractional
-
Short Fractional - Simulated Check Rail
-
Tall Fractional
-
Tall Fractional - Simulated Check Rail
Glass
Product Options
-
Low-E SmartSun™ Tempered Glass
SmartSun™ glass gives you the benefits of Low-E glass, plus it helps shield your home from the sun's heat by filtering out harmful UV rays.
Ideal for: All Climates
Low-E SmartSun™ with HeatLock Coating is also available on 100 Series windows and doors. This prevents more heat from escaping your home but slightly reduces the visible light transmitted through the glass.
-
Low-E Tempered Glass
Low-E Glass reflects heat in the summer and helps to retain interior heat in the winter.
Ideal for: All Climates
Low-E with HeatLock Coating improves the U-Factor performance of the window but slightly reduces how much light comes through the glass.
-
Dual-Pane Tempered Glass
Clear dual-pane glass, which offers basic thermal performance, is in situations where codes allow its use. In North Texas, clear-dual pane glass does not meet energy code.
See local code official for requirements in your area.
-
HeatLock® Technology
HeatLock® coating reflects heat that likes to escape your home through window glass. It can be added to most of Andersen's glass options.
Decorative and Specialty Glass
-
Safety Glass
Tempered safety glass is available on all products, and comes standard on all patio doors.Sound-Reducing Glass
This glass helps reduce the volume of outside noise. Available with Low-E, SmartSun and HeatLock coatings.Patterned Glass
Let in light while obscuring vision and adding a unique decorative touch to your home.
Screens & Blinds
Gliding Insect Screen
-
Gliding Insect Screen
The insect screen is available for both two-panel doors and four-panel doors. Gliding insect screens have Delrin® injection-molded bottom rollers with self-contained leveling adjusters, providing smooth operation. Interior and exterior pulls and latch are provided.
-
Retractable Insect Screen
The retractable insect screen is installed on the exterior of the door and opens side-to-side across the width of the opening. When the insect screen is not in use, it neatly retracts into a small canister mounted on the exterior of the door. The retractable insect screen canister is available for two-panel patio doors. Please note, retractable insect screen track reduces clear opening height by 1".
Blinds-Between-the-Glass
-
The 200 Series Perma-Shield® Gliding Patio Door is available with the modern convenience of blinds-between-the-glass.
- White blinds are located between the panes of insulated glass, protected from dust and damage
- Easy clean glass
- Cordless design to easily raise, lower or tilt blinds
- Blinds are available on select gliding patio door sizes
- Standard Low-E tempered glass
More Options
Additional Door Options
-
Threshold
An oak or maple threshold is available for finishing the interior of the sill.
-
Ramped Sill Insert
Ramped sills provide a smooth transition from interior to exterior and can be used with a retractable insect screen, but not a gliding insect screen.
-
Sill Support
An aluminum sill support is designed to lock into a channel under the sill and tie back into the wall. This will offer support to the outermost sill section when needed. Available in a neutral gray finish.
-
Sidelights
Stationary units can also be selected for use as sidelights.
Smart Home
-
VeriLock® Security Sensors
With the most advanced technology in the industry, patented VeriLock® sensors not only indicate whether your windows and patio doors are open, they even tell you if they are locked or unlocked.* No other sensors can do that.
- Preserves Beauty.
VeriLock® sensors are wireless to help preserve the beauty of your windows and patio doors and are available in a range of color options to complement your home décor - Helps Maximize Energy Efficiency.
Windows that are closed but unlocked lose air at a rate up to 3X that of a closed and locked window** - Maintains Warranty.
Other sensors require drilling which can void warranties. Our sensors require no drilling and come with their own limited warranty - Monitoring Options.
Available with professional and/or self-monitoring options - Compatibility.
Can be ordered with new Andersen® windows and doors, or added to products already in your home
VeriLock® Sensor Colors
*When properly configured and maintained with a professionally installed security system and/or self-monitoring system compatible with Honeywell® 5800 controls. See your dealer for more information.**Based on testing of (32) A-Series double-hung windows. Air loss through unlocked windows will vary based on window type and age, pressure differential, temperatures inside and outside the home, altitude and application.
- Preserves Beauty.
-
Wireless Open/Closed Sensors
When you want the peace of mind of knowing whether your windows and patio doors are open or closed, these sensors are a simple, reliable solution.
- Preserves Beauty.
Sleek, compact design for a clean appearance and a variety of color options to help sensors blend in with your windows, patio doors, and home décor - Installation.
Easy DIY installation - Maintains Warranty.
Other sensors require drilling which can void warranties. Smart Home Wireless open/closed sensors require no drilling and come with their own limited warranty - Monitoring Options.
Available with professional and/or self-monitoring options - Compatibility.
Available for use with all Andersen® windows and patio doors
Wireless Open/Closed Sensor Colors
- Preserves Beauty.
— Mike C, Review from AndersenWindows.comBought this door a little over a year ago. A vast improvement over my originally installed patio slider. It’s quieter, and well insulated. The internal blinds work well and I can open and close easily with 1 finger!
Product Specs
| Brand | Andersen |
|---|---|
| Series | 200 Series |
| Interior Colors | White, Sandtone, Terratone, Canvas, Dark Bronze, Black |
| Exterior Colors | White, Sandtone, Terratone, Canvas, Dark Bronze, Black |
| Composition | Wood core with vinyl surface |
| Construction Type | Build, Remodel, Replace |
| Standard Heights | 6'8", 6'11", and 8' |
|---|---|
| Standard Widths | Single panel: 3'3-1/8" and 4'3-1/8" | 2-panel: 5', 5'11-1/4", and 8'0-3/4" |
| Custom Sizes | Available in 1/8" increments |
| Jamb Depth | 4-9/16" |
| Energy Star Certification | Yes |
|---|---|
| NFRC Ratings | Yes |
| WDMA Hallmark Certification | Yes |
| AAMA Certification | Yes |
| Glass Warranty | 20-Years |
| Glass Breakage Warranty | No |
| Non-Glass Warranty | 10-Years |
| Labor Warranty | No |
