Andersen 400 Series Frenchwood Hinged Inswing Patio Doors

Andersen 400 Series Frenchwood Hinged Patio Doors

Enhance the style of your home with Frenchwood Hinged Inswing Patio Doors. This door system features a traditional design with modern performance. Time-tested, classic wood craftsmanship makes a beautiful statement and requires little maintenance.

Customize this door for your home by choosing from among four exterior color options, an extensive hardware selection, and several options for grilles and patterned glass.

  • Perma-Shield exteriors never need painting and won't peel, blister, flake, or corrode
  • Frame is protected by a tough vinyl cover that resists dents and repels water
  • The sill features three-piece construction of solid oak and aluminum fortified by Fibrex material
  • Weather-resistant construction for greater comfort and energy efficiency
  • Weatherstripping is designed to seal out drafts, wind, and water

Protected by Andersen's Owner-2-Owner Limited Warranty

Request Pricing Get Brochure

400 Series Brochure

It Worked

Your Andersen 400 Series Frenchwood Hinged Patio Doors Brochure is in your inbox.

  • Features
  • Colors
  • Hardware
  • Grilles
  • Glass
  • Screens
  • Trim
  • More Options
Features
  • Low-Maintenance

    The sill has an extruded aluminum track, with a stainless steel cap that resists stain, rust and denting and an attractive wear-resistant, heat-baked finish in a neutral gray color.

    The exterior frame is covered with rigid vinyl that maintains an attractive appearance while minimizing maintenance. The wood frame is treated with a water-repellent preservative for long-lasting protection and performance.

    A flexible vinyl weatherstrip provides a positive seal between the frame and panels.

  • Adjustable Hinges

    Adjustable hinges are standard on inswing patio doors and have ball-bearing pivots for smooth, frictionless movement. Features easy horizontal and vertical adjustment, plus quick-release feature for easy panel removal. This release feature is ideal for transporting large units up stairs or to other hard-to-reach areas.
  • Maximum Strength

    Panel joints are mortise-and-tenon with patented dowel construction for maximum strength.
  • Enhanced Security

    The multi-point locking system, with a hook bolt above and below the center dead bolt, provides a weathertight seal and enhanced security.

Size and Panel Options

  • Single Panel

    • Width Options: 24-1/2", 30-1/8", 32-1/8", 36-1/8"
    • Height Options: 79-1/2", 82-3/8", 95-1/2"
  • Two Panel

    • Width Options: 48", 59-1/4", 63-1/4", 71-1/4"
    • Height Options: 79-1/2", 82-3/8", 95-1/2"
  • Three Panel

    • Width Options: 107-1/8", 95-1/8"
    • Height Options: 79-1/2", 82-3/8", 95-1/2"
Colors
  • The exterior of the wood door panel is protected with a low-maintenance urethane base finish in White, Sandtone, Terratone or Forest Green color. Panel interior surfaces are unfinished pine, oak or maple veneer. Low-maintenance prefinished vinyl White interiors are also available on units with White exteriors.

Interior

  • White
  • Pine
  • Maple
  • Oak

Exterior

  • White
  • Sandtone
  • Terratone
  • Forest Green
Hardware

Hardware Finishes

  • Antique Brass
  • Black
  • Bright Brass
  • Brushed Chrome
  • Distressed Bronze
  • Gold Dust
  • Oil Rubbed Bronze
  • Polished Chrome
  • Satin Nickel
  • Satin Stainless Steel
  • Stone
  • White

Hardware Styles

  • Albany
  • Tribeca®
  • Anvers®
  • Newbury®
  • Covington™
  • Whitmore®
  • Encino®
  • Yuma®
  • FSB® 1035
  • FSB® 1076
  • FSB® 1075
  • FSB® 1102

Additional Options

  • Exterior Keyed Lock

    A six-pin key cylinder lock is available in styles and finishes that coordinate with hardware and allows the door to be locked and unlocked from the exterior.
  • Handle Extension

    Extends interior door handle an additional 1" or 2" from the door panel to accommodate interior blinds or shades. Extenders are available in finishes that coordinate with hardware.

  • Panel Stop

    The hinged door panel stop helps prevent wall damage when opening the inswing door. Available in finishes that coordinate with hardware.

  • Strike Plate Extender

    Used to extend the strike plate out covering the extension jamb for single-hinge doors.

    Available for the following wall thicknesses:

    • 5 1/4"
    • 6 9/16"
    • 7 1/8"
Grilles

Grille Types

  • Full Divided Light

    Grilles applied to the interior and exterior of the window with aluminum spacers between the glass create an authentic look.

  • Simulated Divided Light

    Style your window with permanent exterior grilles and choose between permanent or removable interior grilles.

  • Removable Interior Grille

    Removable interior grilles make cleaning easy. Secured via a fastener or grille clip, these can be removed easily.

  • Finelight Grilles Between-the-Glass

    Grilles sit between the panes of glass for easy cleaning.

Grille Patterns

  • Prairie
  • Colonial
  • Modified Colonial
  • Modified Colonial - Simulated Check Rail
  • Short Fractional
  • Short Fractional - Simulated Check Rail
  • Tall Fractional
  • Tall Fractional - Simulated Check Rail
  • Specified Equal Light
  • Custom Patterns
Glass

Glass

  • SmartSun™ Tempered Glass

    SmartSun™ glass gives you the benefits of Low-E glass, plus it helps shield your home from the sun's heat by filtering out harmful UV rays.

    Ideal for: All Climates

    SmartSun™ with HeatLock Coating is available on 400 Series products. This prevents more heat from escaping your home but slightly reduces the visible light transmitted through the glass.

  • Low-E4® Tempered Glass

    Low-E4® Glass reflects heat in the summer and helps to retain interior heat in the winter.

    Ideal for: All Climates

    Low-E4® with HeatLock Coating is available on 400 Series products. This improves the U-Factor performance of the window but slightly reduces how much light comes through the glass.

  • PassiveSun® Tempered Glass

    If you live in a cold climate, PassiveSun® glass allows the sun to heat your home.

    Ideal for: Northern Climates

  • Sun Tempered Glass

    Sun glass has excellent thermal performance. This glass has a subtle tint that blocks out more heat from the sun.

    Ideal for: Southern Climates

  • HeatLock® Technology

    HeatLock® coating reflects heat that likes to escape your home through window glass. It can be added to most of Andersen's glass options.

Decorative and Specialty Glass

  • Safety Glass
    Tempered safety glass is available on all products, and comes standard on all patio doors.

    Sound-Reducing Glass
    This glass helps reduce the volume of outside noise.  Available with Low-E, SmartSun and HeatLock coatings.

    Art Glass
    Andersen® art glass is available in a wide variety of patterns adding uncommon elegance to any home style.

    Patterned Glass
    Let in light while obscuring vision and adding a unique decorative touch to your home.

    Andersen patterned glass is available in Cascade, Fern, Obscure, or Reed.

Art Glass

  • Classic Series

    The four styles included in our Classic Series panels represent major architectural design themes from the late 1800's through the 1930's. Their symmetric patterns are available in distinctive color schemes as well as colorless glass, and their caming may be finished with a gold tone, silver tone or antique patina.

  • Artisan Series

    Two designs influenced by 20th century American and European architectural schools feature striking visual patterns that evoke an extraordinary blend of art and nature.

  • Historic Series

Screens
  • All insect screens have a long-lasting fiberglass screen mesh with a charcoal finish and are color matched to the exterior of the door unless otherwise specified.

Insect Screens

  • Gliding Insect Screen

    Patented square corner joints add considerable strength to the frame members. The insect screen is available in a conventional gliding or a premium top-hung gliding design. The conventional insect screen has bottom rollers with self-contained leveling adjusters. The premium top-hung insect screen has silicone-embedded glide hooks that hang from the top of the screen track, allowing it to glide smoothly and effortlessly. Alignment rollers on the bottom of the insect screen keep it in place on the track while the perimeter bug seal helps ensure insects stay on the outside.
  • Hinged Insect Screens

    Available for single-panel hinged doors and two-panel jamb-hinged doors.
  • Double-Insect Screen Track

    An extended insect screen track is available for jamb-hinged doors that use gliding insect screens.
Trim
  • Exterior Trim

    Exterior trim adds a finishing touch to your windows or doors and is often essential in achieving authentic architectural style. You can match the color of your windows or doors, or complement them with a different color.

Trim Colors

  • White
  • Canvas
  • Sandtone
  • Terratone
  • Forest Green
  • Dark Bronze
  • Black
  • Cocoa Bean
  • Red Rock
  • Prairie Grass
  • Dove Gray

Trim Styles

  • 2" Brick Mould
  • 3.5" Flat
  • 4.5" Flat

Head Trim Profiles

  • Decorative Drip Cap
  • 2" Cornice
  • 3 5/8" Cornice
More Options
  • Threshold

    An oak or maple threshold is available for finishing the interior of the sill.
  • Ramped Sill Insert

    Ramped sills provide a smooth transition from interior to exterior and can be used with a retractable insect screen, but not a gliding insect screen.
  • Sill Support

    An aluminum sill support is designed to lock into a channel under the sill and tie back into the wall. This will offer support to the outermost sill section when needed. Available in a neutral gray finish.
  • Sidelights & Transoms

    Sidelights and transoms are available for all Frenchwood hinged patio doors.

Smart Home

  • VeriLock® Security Sensors

    With the most advanced technology in the industry, patented VeriLock® sensors not only indicate whether your windows and patio doors are open, they even tell you if they are locked or unlocked.* No other sensors can do that.

    • Preserves Beauty.
      VeriLock® sensors are wireless to help preserve the beauty of your windows and patio doors and are available in a range of color options to complement your home décor
    • Helps Maximize Energy Efficiency.
      Windows that are closed but unlocked lose air at a rate up to 3X that of a closed and locked window**
    • Maintains Warranty.
      Other sensors require drilling which can void warranties. Our sensors require no drilling and come with their own limited warranty
    • Monitoring Options.
      Available with professional and/or self-monitoring options
    • Compatibility.
      Can be ordered with new Andersen® windows and doors, or added to products already in your home

    VeriLock® Sensor Colors

    Andersen VeriLock Sensor color options: Black, Gold Dust, Stone, Taupe Gray, White

  • Wireless Open/Closed Sensors

    When you want the peace of mind of knowing whether your windows and patio doors are open or closed, these sensors are a simple, reliable solution.

    • Preserves Beauty.
      Sleek, compact design for a clean appearance and a variety of color options to help sensors blend in with your windows, patio doors, and home décor
    • Installation.
      Easy DIY installation
    • Maintains Warranty.
      Other sensors require drilling which can void warranties. Smart Home Wireless open/closed sensors require no drilling and come with their own limited warranty
    • Monitoring Options.
      Available with professional and/or self-monitoring options
    • Compatibility.
      Available for use with all Andersen® windows and patio doors

    Wireless Open/Closed Sensor Colors

    Wireless Open/Closed sensor color options: Dark Bronze, Sandtone, Canvas, Andersen White

Product Specs

Brand Andersen
Series 400 Series
Interior Color Pine, Maple, Oak, White (Prefinished White interiors are only available on units with White exteriors)
Exterior Color White, Sandtone, Terratone, Forest Green
Composition Wood with vinyl exterior
Construction Type Build, Remodel, Replace
Standard Heights 6'8", 6'11" and 8'
Standard Widths Single panel: 2'1", 2'7", 2'9" and 3'1" | 2-panel: 4'1", 5', 5'4" and 6' | 3-panel: 8' and 9'
Custom Sizes Available in 1/8" increments
Swing Options Inswing
Jamb Depth 4 9/16"
Energy Star Certification Yes
NFRC Ratings Yes
WDMA Hallmark Certification Yes
AAMA Certification Yes
Glass Warranty 20 Years
Glass-Breakage Warranty No
Non-Glass Warranty 10 Years
Labor Warranty No
